Specifications:
1)Galvanic isolation 2000VAC
2)Operation: HART-protocol
3)PC programmable temperature transmitter for converting various input signals into a scalable 4 to 20mA analogue output signal
4)Wide voltage supply range
5)Expanded resistance input (max 2kΩ)
6)Expanded voltage input (max 2KmV)
Performance:
* Internal cold junction
* Fault signal on sensor break or short circuit
* 2-wire technology, 4 to 20mA analogue output
* High accuracy in total ambient temperature range
* Customer specific measurement range setting or expanded SETUP
Technical data:
Output:
4 to 20mA
Supply voltage:
7.5 to 45VDC
Input:
RTD, TC, Ohm, mV
Influence of ambient:
Negligible
Load influence:
Negligible
Power supply influence:
Negligible
Resolution:
0.3uA
Installation:
sensor head Form B
Operation:
PC-programmable
